EN8075 Africa
Timeless Design: 4 Cylinder 75 HP Engine Power Domestic TÜMOSAN Engine with High Traction Performance and Low Fuel Consumption
PHOTO GALLERY
HIGHLIGHTED FEATURES
Fuel Tank
Fuel tank with a capacity of 115 liters that provides uninterrupted operation throughout the day.
Hydraulic Control System
Hydraulic Control System that allows ergonomic use positioned right next to the operator.
PTO Shaft
PTO with 540/540E rpm dual speed option.
Lifting Capacity
Hydraulic system with a lifting capacity of 2200 kg in all models.
Valve System
Thanks to the 4 Hydraulic Power Outputs offered as standard, it is possible to work uninterruptedly with the equipment that needs hydraulics.
For all features, you can download our brochure by clicking here
TECHNICIAL SPECIFICATIONS
Engine
Transmission
Pto Shaft
Hydraulic System
Weights
Tire Options (4WD)
| Emission Level | Stage IIIA |
| Rated Motor Power (HP) | 75 |
| Number of Cylinders / Aspiration | 4 / Naturally aspirated |
| Cylinder Displacement (liter) | 3,9 |
| Maximum Torque (Nm) | 320 |
| Maximum Torque Speed (d/dk) | 1500 |
| Air Filter Type | Dry |
| Fuel Tank Capacity (liter) | 115 |
| Gearbox Type | Mechanical - Synchromesh |
| Gear Option | 12 Forward - 3 Backward |
| Forward - Reverse Raceway | Mechanical |
| Two-Wheel Control - 4WD | Mechanical |
| Front Differential Lock - 4WD | Electro - Hydraulic |
| Rear Differential Lock | Mechanical |
| Type | Independent |
| Control Type | Mechanical |
| PTO Speed | Standard |
| PTO Speed | 540 - 540E |
| Engine Speed | 2225 |
| Engine Speed | 1590 |
| Control Type | Mechanical |
| Lift Automatic | Standard |
| Hydraulic Power Output (pcs) | 4 |
| Lifting Capacity (kg) | 2200 |
| Total Front Bag Weight (pcs x kg) | 6x40 |
| Total Counterweight - With Canopy (pcs x kg) | 2x50 |
| Unladen Mass - 4WD Cab (kg) | 3500 |
| 1. Option 4WD-Front | 7.50-18 |
| 1. Option 4WD-Rear | 18.4/15-30 |
